Description

Hikvision DS-3WR4G12C(O-STD)/UK AC1200 Dual-Band 4G LTE Wireless Router with SIM Card Support

The Hikvision DS-3WR4G12C(O-STD)/UK is an AC1200 dual-band 4G LTE wireless router designed to provide flexible internet connectivity for homes, offices, shops, CCTV surveillance systems and locations without fixed broadband access.

With its built-in 4G LTE Cat.4 modem, the router allows users to access the internet using a compatible mobile network SIM card and an active data subscription.

It supports theoretical 4G LTE download speeds of up to 150Mbps and upload speeds of up to 50Mbps, depending on network coverage, mobile operator, signal strength and network conditions.

The router features dual-band Wi-Fi 5 technology, offering wireless link rates of up to 300Mbps on 2.4GHz and 867Mbps on 5GHz, for a combined theoretical wireless rate of 1167Mbps.

Two detachable high-gain antennas help provide wireless connectivity, while two Fast Ethernet ports allow connection to compatible wired network equipment.

The Hikvision DS-3WR4G12C supports 3G/4G Router Mode, Wireless Router Mode and Access Point Mode, making it suitable for different networking requirements.

Its web-based management interface provides access to wireless settings, guest network configuration, Wi-Fi scheduling, security settings and device administration.

Key Features

• Built-in 4G LTE Cat.4 modem
• SIM card internet connectivity
• AC1200 dual-band Wi-Fi 5
• 2.4GHz and 5GHz wireless bands
• Up to 1167Mbps combined theoretical Wi-Fi link rate
• Up to 150Mbps theoretical LTE download speed
• Up to 50Mbps theoretical LTE upload speed
• 2 × 10/100Mbps Ethernet ports
• 2 detachable high-gain antennas
• 2×2 MIMO wireless technology
• 3G/4G Router, Wireless Router and AP operating modes
• WPA/WPA2 wireless security
• Guest Wi-Fi network
• Wi-Fi scheduling
• Web-based management
• Compact desktop design

Technical Specifications

Brand: Hikvision
Model: DS-3WR4G12C(O-STD)/UK
Product Type: 4G LTE Dual-Band Wireless Router
Wireless Standard: IEEE 802.11ac Wi-Fi 5
Wireless Class: AC1200
Wireless Frequencies: 2.4GHz / 5GHz
Maximum Combined Wireless Link Rate: 1167Mbps
2.4GHz Link Rate: 300Mbps
5GHz Link Rate: 867Mbps
Mobile Network: LTE Cat.4 / WCDMA
Maximum LTE Download: 150Mbps
Maximum LTE Upload: 50Mbps
Ethernet Interfaces: 2 × 10/100Mbps RJ45
Antenna: 2 Detachable High-Gain Antennas
MIMO: 2×2
Security: WPA/WPA2
Guest Network: Supported
Management: Web Interface
Power Supply: 9V DC, 1A
Maximum Power Consumption: 9W
Installation: Desktop
Dimensions: 233.9 × 151.4 × 40.3mm

Recommended Applications

• Home internet connectivity
• Small offices
• Shops and retail outlets
• CCTV surveillance installations
• NVR remote viewing
• Temporary offices
• Construction sites
• Remote properties
• Locations without fiber broadband
• Backup internet connections

Package Contents

• Hikvision DS-3WR4G12C 4G LTE Router
• Power Adapter
• 2 Detachable Antennas
• Ethernet Cable
• SIM Card Adapter
• Quick Start Guide
• Manufacturer Documentation

Important Information: A compatible mobile SIM card and active data plan are required for 4G internet access. Mobile operator compatibility and supported LTE frequency bands should be confirmed before purchase.

The router does not include free internet or mobile data. Actual Wi-Fi and 4G speeds depend on the service provider, signal strength, connected devices and network conditions.
